Dave Quinlan

Technical Translation for Design and Manufacturing

CNC Communication

I have worked on CNC machines from early tape fed units to today’s complex computer controls.



I have programmed CNC machines by hand, using CAM software and DNC to communicate between the host PC and the CNC machine.



I have written many custom postprocessors to output CNC code for many controls.



I have set up simple RS232 communication and more complex network communications.



CNC programming and DNC communication

Image taken from http://www.memex.ca/docs/Memex%20Multi-DNC_Sheet.pdf

Image taken from http://www.lammertbies.nl/comm/cable/plc.html
